The capability for biosensing, biomedical imaging, and biomolecular manipulation has become essential in current biomedical research and development. Light is very attractive in that it can be utilized for all these functions. Biophotonics is the study of light interaction with biological matter and it is also recently regarded as the key science for the next generation of clinical tools and biomedical research instruments. This research area, however, is still in need for advanced biomedical imaging techniques, highly sensitive biophotonic sensors, and massive/rapid biomolecular manipulation methods. For last decade, a remarkable achievement in nano/ microscale manufacturing of engineering materials has been rapidly stimulated by MEMS and NEMS (Micro/Nano Electro-Mechanical systems) technology and moreover high sensitive metrological techniques at micro/nanoscale lead physiologists to deeper understanding on the working mechanism of physiological structures in nature.
KAIST Biophotonics laboratory is currently developing next generation functional endoscopy incorporated with biomimetic photonics and bionanoplasmonics.

kihun01

Nature provides innovative solutions for effectively handling photons. For example, compound eyes have extinguished optical schemes for wide field-of-view imaging and fast motion detection in small form factor. Biologically inspired artificial compound eyes featured in Science 2006 as a cover article is one of extraordinary achievements. This work is being developed for endoscopic imaging lenses and illumination lens. Not only lenses, advanced photonic devices inspired from nature’s vision, bioluminescence, and biocamouflage organs are also being actively developed for functional endoscopy. Label-free biosensing is a key requirement for functional endoscopy. Ultra high sensitive biosensing and bioimaging techniques based on nanoplasmonic biosubstrates are being developed. Small molecules such as neurotransmitters are hardly detectable without labeling. Nanoplasmonic biosensing
techniques also enable the detection of small molecules at pico molar level by incorporating nanofluidics and nanopores. Nanophotonic and Microphotonic techniques are currently being empolyed for functional endoscopy based on optical coherence tomography (OCT) and Terahertz time-domain spectroscopy.




Biomimetic Advanced Photonic Devices



kihun02

In nature, animal eyes can be categorized as four types of shadow eyes, camera eyes, compound eyes, and reflective eyes depending on their optical schemes. Each optical scheme has both advantages and disadvantages but fully functional enough to satisfy their need for survival. We have demonstrated several biomimetic efforts for advanced photonic systems. For examples, tunable liquid-filled microlens arrays inspired from autofocus mechanism of human retina and a deformable
CMOS image sensor array mimicking human retina with spherical configuration to minimize optical aberrations. Especially, insect’s compound eyes have been of my most concern among natural optical schemes, because their optical schemes are completely different from others. They have many advantages capable of wide field-of-view detection, polarization detection, spectral sensitivity, and fast motion detection in miniaturized imaging system. Our approach on the demonstration of biomimetic microfabricated compound eyes for omni-directional detection can also be a suitable example for the development of biomimetic advanced photonic devices. The omni-directional optical sensing of insects in a small form factor is one of the most important needs for their survival. Their functionality is achieved by spherically arranging ommatidia that collect impinging light within small angle (‹4°). Each ommatidium consists of a light refracting facet lens, a light-guiding crystal cone and rhabdomere, and photoreceptors. The engineering duplication of the unique 3D structure has been demonstrated by utilizing polymer microlens and a nonlinear UV lithographic process called a self-written waveguide process in a photosensitive polymer resin. This work gives a new paradigm for developing wide field-of-view detection or motion detection in surveillance detectors, mini-robots, and miniaturized imaging systems such as digital cameras or mobile phones.




Biophotonic NEMS/MEMS for Biomolecular Sensing and Biomedical Imaging



kihun03

The development of highly sensitive nano/microscale biophotonic sensors that can improve the fundamental understanding of natural system is of our major interest. A nanomechanical force gauge for force measurement in a pico-newton regime, and dielectro-spectroscopic nanogap electrodes for the dielectro-spectroscopic detection of label-free DNAs/protein conformation and nano-knifes for mechanical cell lysing in a sample preparation biochip have been previously done. In particular, optical coherence tomography similar to low coherence interferometer is the emerging modality for in-depth biomedical imaging. Unlike ultrasonic imaging or confocal imaging, the unique advantage of this method is that the lateral resolution can be achieved down to the diffraction limit with the penetration depth of several millimeters. This technique is recently coupled with endoscopic imaging for early cancer detection. One of the most critical elements is a high speed scanning device within an endoscopic

catheter of few millimeters. Scanning MEMS mirrors, lens scanners, or fiber scanners can be utilized as a fast scanning device. Our approach is focused on the development of MEMS mirrors and lens scanners for OCT based endoscopic catheter that requires the parallel consideration from design to packaging due to spatially restriction.

Key Achievements
  • 1. K. H. Jeong, J. Kim, and L. P. Lee, “Biologically inspired artificial compound eyes,” Science, vol. 312, pp. 557-561, 2006.
  • 2. Y. J. Oh, S. G. Park, M. H. Kang, J. H. Choi, Y. Nam, and K. H. Jeong, “Beyond the SERS: Raman enhancement of small molecules using nanofluidic channels with localized surface plasmon resonance,” Small, vol. 7, pp. 184-188, 2011, featured as a Cover article.
  • 3. H. C. Park, C. Song, M. Kang, Y. Jeong, and K. H. Jeong, “Forward imaging OCT endoscopic catheter based on MEMS lens scanning “, Optics Letters, vol. 37, pp. 2673-2675, 2012.
  • 4. J. J. Kim, Y. Lee, H. G. Kim, K. J. Choi, H. S. Kweon, S. Park, and Ki-Hun Jeong, “Biologically inspired LED lens from cuticular nanostructures of firefly lantern”, Proceedings of the National Academy of Sciences of the United States of America, vol. 109, pp. 18674-18678, 2012.
  • 5. M. Kang, J. J. Kim, Y. J. Oh, S. G. Park, and K. H. Jeong, “Deformable nanoplasmonic membrane reveals universal correlations between plasmon resonance and surface enhanced Raman Scattering”, Advanced Materials, vol. 26, pp. 4510-4514, 2014.
  • 6. Y. J. Oh, J. J. Kim, and K. H. Jeong, “Biologically Inspired biophotonic Surfaces with Self-Antireflection”, Small, vol.10, pp. 2558-2563, 2014.

Achievement In This Year

  • 1. Y.-J. Oh, M. Kang, M. Park and K.-H. Jeong, “Engineering Hot Spots on Plasmonic Nanopillar Arrays for SERS: A Review”, BioChip Journal, vol.10(4), 297-309, December 2016
  • 2. K. Hwang, Y.-H. Seo, and K.-H. Jeong, “Microscanners for Optical Endomicroscopic Applications”, Micro and Nano Systems Letters, vol.5(1), January 2017
  • 3. M. Park, H. Jung, Y. Jeong and K.-H. Jeong, “Plasmonic Schirmer Strip for Human Tear-Based Gouty Arthritis Diagnosis Using Surface-Enhanced Raman Scattering”, ACS Nano, vol.11(1), pp. 438-443, January 2017
  • 4. S.-G. Park, Y. Lee, S. Kwon, S. Yoo, Q..-H. Park, J.-K. Park, and K.-H. Jeong, “Extraordinary Figure-of-Merit of Magnetic Resonance from Ultrathin Silicon Nanohole Membrane as All-Dielectric Metamaterial”, Advanced Optical Materials, vol. 5(3), February 2017 (equally contributed to this work)
  • 5. Y. Lee, S. G. Park, S. Yoo , M. Kang, S. C. Jeon, Y. S. Kim, Q. H. Park, and K.-H. Jeong, “Optically Patternable Metamaterial Below Diffraction Limit”, ACS Applied Materials and Interface, vol. 9(22), pp. 18405–18409, June 2017
  • 6. J.-B.Kim and K.-H.Jeong, “Batch fabrication of functional optical elements on a fiber facet using DMD based maskless lithograpy”, OPTICS EXPRESS, vol. 25(14), pp. 16854-16859, July 2017
  • 7. C. S. Hwang, S. P. Yang, K. W. Jang, J. W. Park, and K.-H. Jeong, “Angle-Selective Optical Filter for Highly Sensitive Reflection Photoplethysmogram”, Biomedical Optics Express, vol. 8(10), pp. 4361-4368, October 2017
  • 8. K. Hwang, Y.-H. Seo, J. Ahn, P. Kim and K.-H. Jeong, “Frequency selection rule for high definition and high frame rate Lissajous scanning”, Scientific reports, October 2017
  • 9. M. Kang, M.-S. An, Y. Lee, and K.-H. Jeong, “Bioplasmonic Alloyed Nanoislands Using Dewetting of Bilayer Thin Films”, ACS Applied Materials and Interface, vol. 9(42), pp. 37154-37159, October 2017
